German Manufactured Aeroflow part storage electric radiators provide heating exactly where you want at exactly the times you want. With these German electric heating systems there is no more trying to predict the weather with old fashioned night storage heaters.


Dynamic Storage German Electric Radiators



Aeroflow German heating Radiators continuously generate and conserve heat within the core of the heater. The heat retention is achieved by a series of fireclay heat plates in the centre of the radiator with up to 20 individual plates for a single radiator. Each heat plate has a coiled heating element totally buried within it, forming an integral part of the plate. Each heat plate has a typical power rating of 100 watts. When the electric heating system is switched on, the element gets hot, heating the storage plate within a matter of minutes. Once heated the heat plate will retain heat for well over 30 minutes, transferring heat to the metal casing and flutes of the Radiator.




Thermostatic Control

Each Aeroflow German radiator has a built in digital electronic room thermostat and 7 day programming system. Optionally they can be controlled remotely by radio frequency. The electronic thermostat is accurate to +/- 0.2 deg C and the timing system allows you to pre-set required room temperatures at specific times. As the temperature drops in a room the thermostat senses the change and switches the heater on, perhaps for only a minute to re-heat the internal plates. This continual dynamic re-heat process continues thereby maintaining the room temperature. This ability to sense temperature changes and react immediately to them is one of the great benefits of this type of heating. Because of this ability to heat up quickly and store heat, the use of electricity is limited and the cost of using the dynamic storage heaters can be just a few pence per hour. Recent tests in the UK have confirmed the low running costs. These tests have shown that not only do these German heaters heat the room to a comfortable even temperature but also keeps the floor temperature within a few degrees of the ambient room temperature.



Dynamic Storage German Radiators

Not to be confused with night storage heaters, which require an overnight charge, dynamic storage German electric radiators can be used any part of the day or night. The dynamic storage German heaters are designed to run on standard electricity tariffs however special tariffs are available offering low cost electricity overnight, during the day and also during the evening. Manufactured to the high engineering standards for which German engineering is renowned and have a 30 YEAR GUARANTEE. The German Dynamic Storage Radiators have been available throughout Europe for more than 30 years. The dynamic storage radiators are produced in the most modern factory of its kind with the most up to date production and powder coating facilities. This company has recently been awarded a gold medal for design and innovation. Recent tests have confirmed that the product is manufactured to the very latest European safety standards achieving both CE and GS marks confirmed by VDE (Verband Der Elektrotechnik) Testing and certification Institute. Independent tests confirm the economic running of these units.


Why Aeroflow German Storage Radiators ?
    • No maintenance
    • Fully controllable
    • No fuel storage required
    • Only pay for fuel as its used
    • No smells
    • No exhaust gases
    • Simple installation
    • Fully automatic controls
    • Ideal conservatory heater
    • Available wall mounted or free standing
    • 30 Year guarantee ( 2 years guarantee on the thermostats )
    • High Performance
    • Absolutely no servicing costs
    • Long lifespan ensured by quality materials and excellent construction


Aeroflow Technical Information


The heart of the Aeroflow German radiator is a refractory block combining a unique storage material with modern design and technology into one highly efficient heating unit.
The heat is transferred within minutes from the internal blocks to the specially designed flutes, which radiate heat and start the convection process. This provides an optimum of radiated, convected and stored heat to provide all round warmth.



Schematic showing radiation and convection output.
Radiator Section Details
1. Heating element
2. Refractory clay plate
3. Steel housing for refractory plate.
4. Hollow flutes
5. Heavy duty powder coating
6. Air movement through ribs
7. Radiation into room

Aeroflow for conservatories
Aeroflow radiators are available in 300mm height for use in conservatories or under low window sills.


This is the ideal solution for conservatory heating, negating the need for piping from the central heating system and instantly creating a single heating zone, which will ensure your conservatory is always the temperature that you want.


Installing Aeroflow electric radiators for your conservatory will mean that you get the maximum from your conservatory investment, being able to use the space all year round, even in the coldest of winters.
Electrorad are the sole U.K. supplier of Aeroflow electric radiators.


Model Specification Guide
Suitable for room types / sizes up to (M3)*
ModelRef. Watts Height mm Width mm Depth mm Weightkg Old New Conservatory S/G D/G
AF 01 650 615 380 90 17 14 19 10 12
AF 03 1300 615 680 90 30 31 36 19 24
AF 05 2000 615 980 90 42 48 62 31 38
AF 07 2500 615 1280 90 55 58 77 36 46
AF 12 1200 300 980 90 25 31 36 19 24
AF 14 2000 300 1580 90 40 48 62 26 38
* Length x Width x Height = cubic metres
OLD – Solid walls, little/no insulation. (If also single glazed go up a model)
NEW – Insulated cavity walls, floor & roof. UPVC double glazing.
